Eco-friendly and Waste Tire Oil Pyrolysis Machine Recycling Line for 38tons

Waste Tire Oil Pyrolysis Machine Recycling Line

Model of waste tire pyrolysis oil plant:

Working process of scrap tire fuel pyrolysis plant:


First, the scrap tyres are put into the reactor, and then seal the feeding in door, later start the machine and the reactor will be rotating and heated by coal, natural gas, wood or electricity. When the temperature reaches the degree of 250 to 280, we will get the crude oil, the oil steam will be continuous produced until the temperature reaches 350-460°C; oil steam will flow through oil gas separator, light component will enter the condensers and meanwhile the heavy oil will be discharged automatically into in heavy oil tank. The liquefied part will be condensed as crude oil, and the part which cannot be liquefied will be transferred by the water seal back to the burning chamber to be reused as heating material.

End of Product from  tire oil pyrolysis plant:

Oil recycling machine Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate the 15 tons waste tire pyrolysis plant.

Oil recycle Land requirement:  300sq meters(10m*30m)

Tire oil machine Exporting Experience:
