300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling

Large Image : 300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling

Product Details:

Place of Origin:	Henan, China

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$45,000.00/sets >=1 sets
Packaging Details:	15 tons waste tire pyrolysis plant in Seaworthy packing
Supply Ability:	200 Set/Sets per Year

Contact Now

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling

Description

Type:	15 Tons Waste Tire Pyrolysis Plant	Condition:	New
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Warranty Of Core Components:	1 Year	Core Components:	PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump, Reactor
Tire Machine Type:	Tire Recycling Machine	Voltage:	380V
Dimension(LWH):	2800mm*7700mm	Year:	2023
Warranty:	1 Year	Key Selling Points:	Energy Saving
Power (kW):	17.5 KW	Weight (KG):	38000 KG
Applicable Industries:	Manufacturing Plant, Energy & Mining	Showroom Location:	United States, Viet Nam, Philippines, Brazil, Peru, Pakistan, India, Mexico, Russia, Thailand, South Korea, Chile, Colombia, Bangladesh, South Africa, Uzbekistan, Malaysia
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Application:	Waste Tire Pyrolysis Plant Fuel Oil Refining Line Recycling Type
Reactor Material:	Q245 345R Boiler Steel	Plate Thickness:	18mm
Handling Capacity:	15 Tons	Machine Weight:	38tons
Cooling System:	Water Cooling	Heating Method:	Direct Heating
Installation:	Free Of Charge	Area Required:	300sq Meter
Port:	FOB LIANYUNGANG

15 TPD Waste Tire Oil Pyrolysis Machine For Oil Recycling 300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 0

Model of waste tire pyrolysis oil plant:

Model	Reactor size	Material	Handling capacity/batch	Seaworthy packing
LJ-8	2200*6000mm	Q245R /Q345R boiler steel ,16mm thickness	5 tons	2*40HQ
LJ-9	2200*6600mm		8tons	2*40HQ
LJ-10	2600*6600mm		10tons	140FR+140HQ
LJ-12	2800*6600mm	Q245R/Q345R boiler steel ,18mm thickness	12tons
LJ-15	2800*7700mm	Q245R/Q345R boiler steel ,18mm thickness	15tons

Working process of 15 TPD Waste Tire Oil Pyrolysis Machine For Oil Recycling:

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 1

First, the scrap tyres are put into the reactor, and then seal the feeding in door, later start the machine and the reactor will be rotating and heated by coal, natural gas, wood or electricity. When the temperature reaches the degree of 250 to 280, we will get the crude oil, the oil steam will be continuous produced until the temperature reaches 350-460°C; oil steam will flow through oil gas separator, light component will enter the condensers and meanwhile the heavy oil will be discharged automatically into in heavy oil tank. The liquefied part will be condensed as crude oil, and the part which cannot be liquefied will be transferred by the water seal back to the burning chamber to be reused as heating material.

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 2

End of Product from tire oil pyrolysis plant:

NO.	Name	Percentage	Usage
1	Tyre oil	40%~45%	* can be sold directly as fuel. * can be refine to diesel and gasoline by oil distillation plant
2	Carbon black	37%	* can be sold directly. * can be refined by carbon black processing machine to make it finer (1500mesh finer). *can be made into pellet by pellet machine
3	Steel wire	13%	*can be sold directly as steel or iron.
4	Waste gas	5%	* can be recycled to heat up the reactor

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 3

Oil recycling machine Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate the 15 tons waste tire pyrolysis plant.

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 6

Oil recycle Land requirement: 300sq meters(10m*30m)

Tire oil machine Exporting Experience:

America:	Brazil, Canada, Colombia, USA,
Middle East:	Dubai, Jordan, Saudi Arabia, Turkey
Europe:	Albania , Bosnia and Herzegovina
Asia:	Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar,Thailand
Africa:	Ghana, Mozambique, Zambia

300sq meter Area Required 15 TPD Waste Tire Oil Pyrolysis Machine for Oil Recycling 8
