Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires

Large Image : Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires

Product Details:

Place of Origin:	Henan, China
Brand Name:	Sihai
Certification:	CE ISO

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$45,000.00/sets >=1 sets
Packaging Details:	New arrival waste tire pyrolysis plant by Seaworthy packing
Supply Ability:	200 Set/Sets per Year

Contact Now

Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires

Description

Type:	New Arrival Waste Tire Pyrolysis Plant	Condition:	New
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Warranty Of Core Components:	1 Year	Core Components:	PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
Tire Machine Type:	Tire Recycling Machine	Voltage:	380V
Dimension(LWH):	2800mm*6600mm	Year:	2021
Warranty:	1 Year	Key Selling Points:	High-accuracy
Power (kW):	17.5 KW	Weight (KG):	32000 KG
Applicable Industries:	Manufacturing Plant, Construction Works , Energy & Mining	Showroom Location:	United States, Viet Nam, Philippines, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Russia, Thailand, Morocco, Argentina, Bangladesh, South Africa, Kazakhstan
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Application:	New Arrival Waste Tire Pyrolysis Plant
Reactor Material:	Q245R Boiler Steel	Plate Thickness:	18mm
Handling Capacity:	12 Tons	Cooling System:	Water Cooling
Heating Method:	Direct Heating	Installation:	Free Of Charge
End Product:	Fuel Oil Steel Carbon Back	Marketing Type:	New Product 2020
After Warranty Service:	Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service	Local Service Location:	United States, Viet Nam, Philippines, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Russia, Thailand, Malaysia, South Korea, Colombia, South Africa, Kazakhstan
Port:	FOB LIANYUNGANG

New arrival waste tire pyrolysis plant

Model of Pyrolysis plant :

Model	Reactor size	Material	Handling capacity/batch	Weight	Seaworthy packing
LJ-8	2200*6000mm	Q245R /Q345R boiler steel ,16mm thickness	5 tons	24tons	2*40HQ
LJ-9	2200*6600mm	Q245R /Q345Rboiler steel ,16mm thickness	8tons	26tons	2*40HQ
LJ-10	2600*6600mm	Q245R /Q345Rboiler steel ,16mm thickness	10tons	30tons	140FR+140HQ
LJ-12	2800*6600mm	Q245R/Q345R boiler steel ,18mm thickness	12tons	32tons	140FR+140HQ
LJ-15	2800*7700mm	Q245R/Q345R boiler steel ,18mm thickness	15tons	40tons	140FR+140HQ

Working process of New arrival waste tire pyrolysis plant tire recycle to oil:

First, the raw materials are put into the reactor, and then seal the feeding in door, later start the machine and the reactor will be rotating and heated by coal, natural gas, wood or electricity. When the temperature reaches the degree of 250 to 280, we will get the crude oil, the oil steam will be continuous produced until the temperature reaches 350-460°C; oil steam will flow through oil gas separator, light component will enter the condensers and meanwhile the heavy oil will be discharged automatically into in heavy oil tank. The liquefied part will be condensed as crude oil, and the part which cannot be liquefied will be transferred by the water seal back to the burning chamber to be reused as heating material.

Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires 1

End of Product from scrap tire recycling pyrolysis plant:

NO.	Name	Percentage	Usage
1	Tyre oil	40%~45%	* can be sold directly as fuel. * can be refine to diesel and gasoline by oil distillation plant
2	Carbon black	37%	* can be sold directly. * can be refined by carbon black processing machine to make it finer (1500mesh finer). *can be made into pellet by pellet machine
3	Steel wire	13%	*can be sold directly as steel or iron.
4	Waste gas	5%	* can be recycled to heat up the reactor

Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate the tire oil pyrolysis plant.

Oil refining production Line Land requirement: 300sq meters(10m*30m)

Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires 6

New Energy Tire to Fuel oil Exporting Experience:

America:	Brazil, Canada, Colombia, USA,
Middle East:	Dubai, Jordan, Saudi Arabia, Turkey
Europe:	Albania , Bosnia and Herzegovina
Asia:	Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar, Thailand, Uzbekistan
Africa:	Ghana, Mozambique, Zambia

Eco-Friendly Waste Processing 2021 Direct Heating Pyrolysis Plant for Waste Tires 9
