Raw Material Rubber 2022 Thermal Cracking Machine Refines Waste Tyres to Oil Equipment

Model:LJ-12                                                    Raw material:Waste tire, waste plastic, waste rubber

Structure:Horizontal                                       24hours processing capacity:12tons raw materials

24hours oil output:5.4 tons fuel oil             Work pressure:Atmospheric

Host speed:0.4r\min                                      Power:17.5KW

Cooling:Water cooling                                    Lose water(T\H):8

Transport:External gear drive                         Heating method:Directly

Installation:Foundation                                  Noise dB(A):≤85

Reactor size length*wideth:2800x6600           Working form:batch

Weight of Reactor(T):36                                Manufacuring time:20days

a. Waste gas: Transferred through two safety device: water close &burning air nozzle. Fully burnt, not only eliminated pollutant but also minimized the quantity of fuels. For smoke dust discharge, we apply series machines of patent in our company Desulphurization and dust remover which could control the smoke dust discharge amount meet relative standards of GB-2001.

b. Waste liquid: Produced waste acidic water in the process of oil disposing (50kg process from 1 ton of oil easy to process for small quantity). counteract the liquid by alkalescent liquid solution. After three stage of filtration, the litmusless wa ste water was introduced to evaporator(use the heat of the flue of main processor as its heating resource)

c. Waste solid. The solid residua will be left after the catalyst splitting from scrap plastic, approximately composes the waste plastic weight about 5% to 10%. Its main component is the thick black carbon. It can be the raw material of the production industry of black carbon. Also could be mixed with the pulverized coal ash which produces for the raw material thermal power plant, also could be the raw material of manufacture pulverized coal ash brick (one kind of environmental protection building material).

1, To improve the quality and functions of products is our purpose, customer's satisfaction is our principle.

2, With fast and practical feed and slag system.

  Efficient gas heating system.

3, stable product quality , supply, the         lifetime after sale.
